1.It can be installed without shutting off the power.
2.Light weight and small diameter reducing the load caused by ice and wind and the load.
3.Good performance of tensile strength and temperature performance.
Geometrical Characteristics
| Fiber Core | 24 | |
| Cable Dimension(mm) | 12 | |
| Cable Weight(kg/km) | 118 |
Mechanical Characteristics
| Tensile Strength(N) | Long Term | 1900 |
| Short Term | 4800 | |
| Crush Resistance(N/100cm) | Long Term | 300 |
| Short Term | 1000 | |
| Bending Radius(cm) | Dynamic | 30xD(D:Cable Diameter) |
| Static | 10xD(D:Cable Diameter) |
Fiber
| Fiber Type(core/cladding dimension) | G652D G655 G657 50/125 62.5/125 |
Transmission Characteristics
| SMF | ||
| 1310(nm) | 1550(nm) | |
| Attenuation(dB/km) | 0.36 dB/km | 0.22 dB/km |
| Minimum Bandwidth(Mhz·km) |
Environmental Characteristics
| Operating Storage Temperature | -40℃~+70℃ |

1.Sheath mechanical and physics performance content correlative standard request.
2.Diameter and bending radius small, lt can installation freely in narrow room.have both optical signal transmission and electricity transmission.

1.Sheath mechanical and physics performance content correlative standard request.
2.Diameter and bending radius small, lt can installation freely in narrow room.have both optical signal transmission and electricity transmission.
